PLC central processing unit, 256 KB work memory, MPI plus PROFIBUS DP master/slave interfaces, 24 V DC supply, 40 mm single-slot profile-rail module.
List Price
$233.38
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Siemens |
|---|---|
| MPN | 6ES7315-2AH14-0AB0 |
| GTIN | 4025515077763 |
| Model | 6ES7315-2AH14-0AB0 |
| Series | Simatic S7-300 CPU 315-2 DP |
|---|---|
| Type | Controller |
| Base Number | 6ES7315 |
| Industry Terms | CPU, central processing unit, PLC processor, CPU 315-2 DP, S7-300 CPU, Zentralbaugruppe, PROFIBUS DP master |
| Common Misspellings | 6ES7 315-2AH14-0AB0, 6ES7315-2AH14-OABO, 6E57315-2AH14-0AB0, Profibus, Simatec, Symatic, Siemsns 6ES7315-2AH14-0AB0 |
| Application Types | Machine and process control panels, packaging and bottling lines, conveyors, water treatment, building services and OEM machinery built on Simatic S7-300 racks with distributed PROFIBUS DP I/O |
| Controller Platform | Siemens Simatic S7-300 |
| Mpn Variants | 6ES73152AH140AB0, 6ES7 315-2AH14-0AB0, 6ES7315 2AH14 0AB0, CPU 315-2 DP |
| Manufacturer Status | Discontinued |
| Additional Attributes | Work Memory: 256 KB, Interfaces: MPI plus PROFIBUS DP master/slave, Supply Voltage: 24 V DC (19.2 to 28.8 V DC), Power Loss: 4.5 W, Bit Processing Time: 0.05 us, Word Processing Time: 0.09 us, Program Storage: Simatic Micro Memory Card, Dimensions: 40 x 125 x 130 mm, Protection Rating: IP20, Operating Temperature: 0 to 60 degC horizontal, 0 to 40 degC vertical |
| Min Temp | 0 °C |
| Max Temp | 60 °C horizontal mounting |
| Nominal Rated Input Voltage | 24 V DC (19.2 to 28.8 V DC) |
| Item Weight | 0.33 kg (0.73 lb) |
| Part Number | 6ES7315-2AH14-0AB0 |
| Mounting Type | Simatic S7-300 profile rail |
| Communication Standard | MPI and PROFIBUS DP (master or slave) |
| Cross Reference 1 | 6ES7315-2EH14-0AB0 - PN/DP, PROFINET 2nd interface |
|---|
Siemens 6ES7315-2AH14-0AB0 central processing unit, Simatic S7-300 CPU 315-2 DP. Part Number: 6ES7315-2AH14-0AB0. Work Memory: 256 KB. Unit Quantity: 1 Pc. One CPU. GTIN: 4025515077763.
6ES7 — Siemens Simatic S7 order-number group.
315-2AH14-0AB0 — CPU 315-2 DP, the S7-300 central processing unit with MPI and a second interface running as PROFIBUS DP master or slave.
Work Memory: 256 KB. Interfaces: MPI, plus a second interface running as PROFIBUS DP master or slave. Supply Voltage: 24 V DC, 19.2 to 28.8 V DC. Power Loss: 4.5 W. Bit Processing Time: 0.05 µs. Word Processing Time: 0.09 µs. Program Storage: Simatic Micro Memory Card. Protection Rating: IP20. Operating Temperature: 0 to 60 °C horizontal, 0 to 40 °C vertical. Item Weight: 0.33 kg (0.73 lb).
Dimensions: 40 x 125 x 130 mm. Mounting Type: Simatic S7-300 profile rail, single slot.
6ES7315-2EH14-0AB0 is the CPU 315-2 PN/DP, the same performance class with a PROFINET second interface. MPN Variants: 6ES73152AH140AB0, 6ES7 315-2AH14-0AB0, CPU 315-2 DP.
Work Memory: 256 KB.
MPI, plus a second interface running as PROFIBUS DP master or slave.
Supply Voltage: 24 V DC, 19.2 to 28.8 V DC. Power Loss: 4.5 W.
