Availability:
1 in stock
Deep groove ball bearing, 25 mm bore, 52 mm OD, 15 mm width, non-contact rubber seals both sides, CM motor clearance, P5 precision. NSK 6205VVCMP5.
List Price
$42.48
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NSK |
|---|---|
| MPN | 6205VVCMP5 |
| Model | 6205VVCM |
| Bearing Type | Deep Groove Ball Bearing, Non-contact seals both sides |
| ID | 25 mm |
| OD | 52 mm |
| Width | 15 mm |
| Material | Steel |
|---|---|
| Series | 6200 |
| Lubricant | Grease |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.1 |
| Internal Clearance | CM |
| Overall Width | 15 mm |
| Mpn Variants | 6205VVCMP5, 6205-VV-CM-P5, 6205VVCM, 6205VV, 6205 VV CM P5 S6NH |
| Precision Class | ABEC 5 / P5 |
| Industry Terms | 6205 sealed deep groove ball bearing; 25x52x15 bearing; electric motor bearing; ABEC 5 sealed bearing; CM clearance bearing |
| Common Misspellings | 6205 VVCMP5; 6205VVCM P5; NSK6205VVCMP5; NKS 6205VV; 6205VV CMP5 |
| Application Types | Electric motors; pumps; fans and blowers; gearboxes; general industrial machinery |
| Cross Reference 1 | SKF 6205-2RZ - CN clearance, standard precision |
|---|---|
| Cross Reference 2 | FAG 6205-2RSR - contact seals, CN, standard precision |
| Cross Reference 3 | NTN 6205LLB - CN clearance, standard precision |
NSK 6205VVCMP5 is a single-row deep groove ball bearing in the 6205 size, with non-contact rubber seals on both sides, NSK CM electric-motor clearance and P5 precision.
6205 — single-row deep groove ball bearing, 02 dimension series, bore code 05 = 25 mm.
VV — NSK non-contact rubber seals on both sides. Low friction with the seal lip running clear of the inner ring.
CM — NSK radial internal clearance for electric motors, a controlled range for quiet running.
P5 — ISO precision class 5, equivalent to ABEC 5.
Bore Diameter: 25 mm. Outside Diameter: 52 mm. Overall Width: 15 mm. Closure Type: Non-contact seals both sides. Internal Clearance: CM. Precision Class: ABEC 5 / P5. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Series: 6200. Unit Quantity: 1 Pc.
The 25 x 52 x 15 mm envelope fits shaft seats and housings machined for any 6205. The bearing is sealed and lubricated for life.
Cross-references: SKF 6205-2RZ (CN clearance, standard precision), FAG 6205-2RSR (contact seals, CN clearance, standard precision) and NTN 6205LLB (CN clearance, standard precision). All are sealed 25 x 52 x 15 mm bearings.
Non-contact rubber seals on both sides.
NSK electric-motor radial internal clearance.
25 mm bore, 52 mm outside diameter, 15 mm width.
