Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Single-row cylindrical roller bearing, 40 x 68 x 15 mm, machined brass cage. Non-locating NU design, 28,500 N dynamic rating.
List Price
$114.60
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | NU1008MP |
| Model | NU1008 MP |
| Bearing Type | Cylindrical Roller Bearing, Open |
| ID | 40 mm |
| OD | 68 mm |
| Width | 15 mm |
| Material | Bearing steel |
|---|---|
| Series | NU 10 |
| Base Number | NU 1008 |
| Mpn Variants | NU1008MP; NU 1008 MP; NU1008M; NU1008 |
| Precision Class | RBEC 1 / P0 |
| Closure Type | Open |
| Dynamic Load Rating | 28,500 N |
| Static Load Rating | 26,000 N |
| Rolling Elements | Cylindrical Roller |
| Cage Material | Machined brass |
| Number Of Rows | 1 |
| Bore Type | Cylindrical |
| Snap Ring Included | Without Snap Ring |
| Limiting Speed | 18,000 rpm |
| Harmonization Code | 8482.50.00.00 |
| Expansion Type | Non-locating, 2.4 mm permissible axial displacement |
| Bearing Material | Bearing steel |
| Cross Reference 1 | FAG NU1008-M1 |
|---|---|
| Cross Reference 2 | NSK NU1008M |
| Cross Reference 3 | NTN NU1008 |
| Cross Reference 4 | Koyo NU1008 |
| Cross Reference 5 | NACHI NU1008 |
SKF NU 1008 MP single-row cylindrical roller bearing. Bore Diameter: 40 mm. Outside Diameter: 68 mm. Overall Width: 15 mm. Number Of Rows: 1. Rolling Elements: Cylindrical Roller. Bore Type: Cylindrical. Cage Material: Machined brass. Closure Type: Open. Bearing Material: Bearing steel. Expansion Type: Non-locating. Series: NU 10. Base Number: NU 1008.
NU is the cylindrical roller design with two integral ribs on the outer ring and a plain, ribless inner ring. 1008 is the 10 extra-light dimension series at a 40 mm bore. M is a machined brass cage. Written as NU1008MP, NU 1008 MP and NU1008.
Dynamic Load Rating: 28,500 N. Static Load Rating: 26,000 N. Reference Speed: 12,000 rpm. Limiting Speed: 18,000 rpm. Line contact between roller and raceway is what gives a cylindrical roller several times the radial capacity of a ball bearing on the same envelope. The NU design lets the rollers run freely along the plain inner ring, so the shaft can grow axially inside the bearing by up to 2.4 mm as it warms — that is the non-locating position in a two-bearing shaft arrangement. A machined brass cage is strong, tolerant of high speed and shock, and works well with oil lubrication.
Unit Quantity: 1 Pc. One bearing per sale unit, open on both faces.
Permissible axial displacement: 2.4 mm maximum. Spacer sleeve diameter da: 43 mm minimum to 46 mm maximum. Shaft abutment diameter db: 49 mm minimum. Housing abutment diameter Da: 62.3 mm maximum. Shaft fillet radius ra: 1 mm maximum. Housing fillet radius rb: 0.6 mm maximum. Bearing chamfers r1,2: 1 mm minimum and r3,4: 0.6 mm minimum. Inner ring raceway diameter F: 47 mm. Outer ring shoulder diameter D1: approximately 57.6 mm. Calculation factors e 0.2 and Y 0.6.
NU 1008 is an ISO-pattern designation and the machined brass cage code translates across makers. Cross-Reference 1: FAG NU1008-M1. Cross-Reference 2: NSK NU1008M. Cross-Reference 3: NTN NU1008. Cross-Reference 4: Koyo NU1008. Cross-Reference 5: NACHI NU1008. Searchable forms: NU1008MP, NU 1008 MP, NU1008M, NU1008.
