Availability:
1 in stock
Super-precision angular contact ball bearing, 55 x 100 x 21 mm, 15° contact angle, ABEC 7 / P4, light preload, one bearing of a universal duplex pair.
List Price
$137.22
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | E255-7CE1DUL |
| Model | 2MM-211 WI DUL / 7211-C P4 DUL / E 255-7 CE 1 DU L |
| Bearing Type | Angular Contact Ball Bearing |
| ID | 55 mm |
| OD | 100 mm |
| Width | 21 mm |
| Mpn Variants | E255-7CE1DUL-1/2PR, E255-7CE1DUL, E 255 7CE1 DUL, E-255-7-CE-1-DUL |
|---|---|
| Precision Class | ABEC 7 / P4 |
| Cage Type | Outer-ring guided |
| Dynamic Load Rating | 55,300 N |
| Static Load Rating | 43,000 N |
| Series | E 200 (ISO 02) |
| Item Weight | 0.603 kg (1.33 lb) |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Snap Ring Included | No |
| Limiting Speed | 14,000 rpm grease; 22,000 rpm oil |
| Contact Angle | 15° |
| Preload | Light |
| Mounting Arrangement | Universally ground single bearing (back-to-back, face-to-face or tandem) |
| Cross Reference 1 | SKF 7211 CDGA/P4A |
|---|---|
| Cross Reference 2 | SKF 7211 CD/P4A |
| Cross Reference 3 | FAG B7211-C-T-P4S-UL |
| Cross Reference 4 | NSK 7211CTYNSULP4 |
| Cross Reference 5 | Fafnir 2MM211WICRSUL |
SNFA E255-7CE1DUL-1/2PR is one super-precision single-row angular contact ball bearing from a factory SNFA E255-7CE1DUL universal duplex pair, SNFA E 200 series, ISO dimension series 02. Bore Diameter: 55 mm. Outside Diameter: 100 mm. Width: 21 mm. Contact Angle: 15°. Precision Class: ABEC 7 / P4. The current SKF equivalent is the 7211 CD/P4A high-capacity D design.
E2 — SNFA E 200 series, ISO dimension series 02 (72xx envelope).
55 — bore diameter in millimetres.
7 — SNFA precision grade, ABEC 7 (ISO P4).
C — phenolic resin cage.
E — cage centred on the outer ring.
1 — 15° contact angle.
DU — universal duplex grinding: the faces are ground for back-to-back, face-to-face or tandem mounting.
L — light preload.
1/2PR — one bearing, half of the matched pair.
Dynamic Load Rating: 55,300 N. Static Load Rating: 43,000 N. Limiting Speed: 14,000 rpm grease; 22,000 rpm oil-air. The 15° angle favours radial stiffness and speed.
Item Weight: 0.603 kg (1.33 lb). Cage Type: Outer-ring guided. Cage Material: Phenolic. Closure Type: Open.
Unit Quantity: 1 Pc. Mounting Arrangement: Universally ground single bearing, pairs with another E255-7CE1DUL bearing. Preload: Light.
SKF owns SNFA and lists the E 200 series as the SNFA equivalent of its 72 .. D range. Cross-references with the same 55 x 100 x 21 mm envelope and 15° contact angle: SKF 7211 CDGA/P4A, SKF 7211 CD/P4A, FAG B7211-C-T-P4S-UL, NSK 7211CTYNSULP4, Fafnir 2MM211WICRSUL.
