SKF7209 CD/P4ADGAAngular Contact Ball Bearing – Straight Bore, 45 mm ID, 85 mm OD, 19 mm Width, Open, 15° Contact Angle, Extra Light Preload.

Condition: New

Availability:

1 in stock

SKF angular contact ball bearing, 45 x 85 x 19 mm, 15° contact angle, extra light preload, universally matchable, ABEC 7 / P4A. Open, single row.

Same day shipment

List Price

$122.99

1 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

1 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandSKF
MPN7209 CD/P4ADGA
Model7209 CD P4A DGA / 2MM209WI CR DUL
Bearing TypeAngular Contact Ball Bearing, Open
ID45 mm
OD85 mm
Width19 mm

Technical Specifications

MaterialBearing Steel
Series7200
PreloadExtra light
Precision ClassABEC 7 / P4A
Precision RatingABEC 7 / P4A
Rolling ElementsBall
Number Of Rows1
Bore TypeStraight
Snap Ring IncludedNo
Harmonization Code8482.10.50.68
Contact Angle15°
Mounting ArrangementUniversal
Bearing MaterialBearing Steel
Closure TypeOpen
Industry Termssuper precision angular contact bearing; universally matched spindle bearing; 15 degree angular contact; ACBB
Common MisspellingsSFK 7209 CD/P4ADGA; 7209 CD P4A DGA; 7209CDP4ADGA; 7209 DC/P4ADGA
Application TypesMachine tool spindles; precision gearboxes; high-speed pumps
Mpn Variants7209 CD/P4ADGA; 7209CD/P4ADGA; 7209-CD-P4A-DGA; 7209CDGA/P4A; 7209C-DGA/P4A

Cross-References

Cross Reference 1Fafnir 2MM209WICRDUL - light preload (DUL)
Cross Reference 2FAG B7209C - base designation, class per suffix
Seller Part Number: B-AG3B3#JHXLJO

Product Description

What this part is:

SKF 7209 CD/P4ADGA is a single-row angular contact ball bearing, 45 mm bore, 85 mm outside diameter, 19 mm wide, open, straight bore. Super-precision, universally matchable. Unit Quantity: 1 Pc.

Decoding the designation:

7209 — SKF’s number for the ISO 7209 size, 45 x 85 x 19 mm, in the 72 series angular contact family.

CD — 15° contact angle design.

P4A — ISO P4 / ABEC 7 super-precision class.

DGA — universally matchable, extra light preload when mounted as a set.

Specifications:

Bore Diameter: 45 mm. Outside Diameter: 85 mm. Overall Width: 19 mm. Number Of Rows: 1.

Contact Angle: 15°. Precision Class: ABEC 7 / P4A. Preload: Extra light. Mounting Arrangement: Universal.

Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Bearing Material: Bearing Steel.

Dimensions and mounting:

Bore Diameter: 45 mm. Outside Diameter: 85 mm. Width: 19 mm. Series: 7200.

Compatibility and replacement:

Fafnir 2MM209WICRDUL has the same 45 x 85 x 19 mm envelope and 15° contact angle, with light preload (DUL). FAG B7209C has the same envelope and 15° contact angle; its class and preload follow its own suffix.

Frequently asked questions:

What size is the SKF 7209 CD/P4ADGA?

45 mm bore, 85 mm outside diameter, 19 mm width.

What is the contact angle of the 7209 CD/P4ADGA?

15°. CD is the SKF 15° contact angle design.

What does DGA mean?

DGA is SKF’s universally matchable execution with extra light preload.
