Availability:
1 in stock
SKF super-precision angular contact ball bearing set, 55 mm bore, 80 mm OD, 15° contact angle, P4A class. Two universally matched bearings, 26 mm set width.
List Price
$285.32
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| Model | 71911C D P4A DGC |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 55 mm |
| OD | 80 mm |
| Preload | Medium |
|---|---|
| Base Number | 71911 |
| Industry Terms | spindle bearing; super-precision angular contact; universally matchable pair; duplex set; ABEC 7 spindle bearing |
| Common Misspellings | 71911CD; 7191 1CD; 71911-CD-P4A-DGC; 71911 CDP4ADGC |
| Application Types | Machine tool spindles; grinding spindles; high-speed precision shafts |
| Overall Width | 26 mm (set of 2; 13 mm per bearing) |
| Country Region Of Manufacture | Italy |
| Mpn Variants | 71911 CD/P4ADGC; 71911-CD/P4ADGC; 71911CDP4ADGC; 71911C D P4A DGC; 71911 CD P4A DGC |
| Arrangement Configuration | Universal matching set of 2: back-to-back, face-to-face or tandem |
| Precision Class | P4A |
| Additional Attributes | Design: High-capacity D; Dimension series: ISO 19; Contact type: two-point contact; Ring type: one-piece inner and outer rings |
| Dynamic Load Rating | 31,200 N (set) |
| Static Load Rating | 29,000 N (set) |
| Item Weight | 0.352 kg (0.78 lb) set |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Bearing Material | Bearing steel |
| Cross Reference 1 | FAG B71911-C-T-P4S |
|---|---|
| Cross Reference 2 | NSK 7911CTYNSULP4 |
| Cross Reference 3 | NTN 7911UCG/GNP4 |
| Cross Reference 4 | Timken Fafnir 2MM9311WI |
SKF 71911 CD/P4ADGC is a matched set of two super-precision, high-capacity D design, single row angular contact ball bearings from the SKF 719 extra-light series. The two bearings are ground for universal matching and can be mounted back-to-back, face-to-face or in tandem. Typical service is machine tool spindles and other high-accuracy shafts carrying combined radial and axial load.
719 — ISO dimension series 19, the extra-light cross-section.
11 — bore code, 11 x 5 = 55 mm bore.
CD — high-capacity D internal design with a 15° contact angle.
P4A — ISO P4 dimensional accuracy with running accuracy better than P4.
DG — set of two bearings for universal matching, with matched bore and outside diameters.
Bore Diameter: 55 mm. Outside Diameter: 80 mm. Overall Width: 26 mm for the two-bearing set, 13 mm per bearing. Contact Angle: 15°. The 15° angle favours speed and radial stiffness over axial capacity.
Dynamic load rating: 31,200 N for the set. Static load rating: 29,000 N for the set.
Precision Class: P4A. Number Of Rows: 2 (two single row bearings). Bearing Material: Bearing steel. Seal type: Open. Closure Type: Open. Bore Type: Straight. Item weight: 0.352 kg (0.78 lb) for the set.
Unit Quantity: 2 Pcs, one factory matched set of two bearings. Arrangement / Configuration: universal matching — back-to-back, face-to-face or tandem.
Related 719-series 55 x 80 x 13 mm, 15° super-precision bearings: FAG B71911-C-T-P4S, NSK 7911CTYNSULP4, NTN 7911UCG/GNP4, Timken Fafnir 2MM9311WI. Preload and set arrangement vary by designation suffix on each brand, so confirm the suffix before substituting.
