SKF71911 CD/P4ADGASuper Precision Angular Contact Ball Bearing — 55 mm ID, 80 mm OD, 13 mm Width, 15° Contact Angle, Extra Light Preload, P4A

Condition: New

Availability:

1 in stock

Matched pair of super-precision angular contact ball bearings, 55 x 80 x 13 mm, 15° contact angle, extra light preload, P4A. SKF D design, universally matchable.

List Price

$308.99

1 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

1 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandSKF
MPN71911 CD/P4ADGA
Model71911C D P4A DGA 71911CD/P4A DGA
Bearing TypeAngular Contact Ball Bearing, Open
ID55 mm
OD80 mm
Width13 mm

Technical Specifications

MaterialBearing Steel
Series71900
LubricantOil/Grease
PreloadExtra light, 70 N
Total Width26 mm (pair)
Mpn Variants71911 CD/P4ADGA, 71911-CD/P4ADGA, 71911CDP4ADGA, 71911 CD P4A DGA, 7911
Precision ClassABEC 7 / P4A
Additional AttributesAxial stiffness 49 N/um; ball diameter 7.938 mm; 23 balls per bearing; da 59.6 mm; Da 75.4 mm; ra max 1 mm; oil nozzle dn 64.7 mm; grease quantity 2.5 cm3 per bearing
Dynamic Load Rating31,200 N (pair)
Static Load Rating29,000 N (pair)
Rolling ElementsBall
Number Of Rows1
Bore TypeStraight
Snap Ring IncludedNo
Limiting Speed12,960 rpm grease; 21,060 rpm oil-air (back-to-back pair)
Harmonization Code8482.10.50
Contact Angle15°
Mounting ArrangementUniversally matchable pair (back-to-back, face-to-face or tandem)
Industry Termssuper precision angular contact ball bearing; matched bearing pair; universally matchable bearing set; machine tool spindle bearing; ABEC 7 angular contact; P4 angular contact bearing
Common MisspellingsSKF 71911CD/P4ADGA; SFK 71911 CD; SKF 71911 CD P4A DGA; SKF 71911CDP4ADGA; SKF71911 CD/P4ADGA
Application TypesMachine tool spindles; high-speed motor spindles; precision grinding spindles; precision instruments

Cross-References

Cross Reference 1FAG B71911-C-T-P4S-DUL – light vs extra light preload
Cross Reference 2NSK 7911CTYNDULP4 – light preload, polyamide cage
Cross Reference 3Fafnir 2MM9311WI DUL – light vs extra light preload
Seller Part Number: B-AL1B3#ALRC9J

Product Description

What this part is:

SKF 71911 CD/P4ADGA is a matched set of two super-precision, high-capacity D design single row angular contact ball bearings, universally matchable for back-to-back, face-to-face or tandem mounting. Unit Quantity: 2 Pcs, one factory-matched pair.

Decoding the designation:

719 — ISO 19 ultra-light series.

11 — bore code, 11 x 5 = 55 mm.

CD — 15° contact angle, SKF high-capacity D internal design.

P4A — SKF tolerance class: ISO P4 dimensional accuracy with P2 running accuracy.

DG — matched set of two bearings, universally matchable in any arrangement.

A — extra light preload.

Specifications:

Bore Diameter: 55 mm. Outside Diameter: 80 mm. Width: 13 mm per bearing. Total Width: 26 mm (pair). Contact Angle: 15°. Precision Class: ABEC 7 / P4A. Preload: Extra light, 70 N. Number Of Rows: 1. Rolling Elements: Ball. Closure Type: Open.

Dynamic Load Rating: 31,200 N (pair). Static Load Rating: 29,000 N (pair). Limiting Speed: 12,960 rpm grease; 21,060 rpm oil-air (back-to-back pair). Single bearing: 16,000 rpm grease; 26,000 rpm oil-air. Axial Stiffness: 49 N/µm. Ball Diameter: 7.938 mm. Number of Balls: 23 per bearing.

Dimensions and mounting:

Shaft Abutment Diameter (da min): 59.6 mm. Housing Abutment Diameter (Da max): 75.4 mm. Fillet Radius (ra max): 1 mm. Chamfer (r1,2 min): 1 mm. Oil Nozzle Position (dn): 64.7 mm. Reference Grease Quantity: 2.5 cm³ per bearing.

Compatibility and replacement:

Cross-references, all 55 x 80 x 13 mm with 15° contact angle: FAG B71911-C-T-P4S-DUL (light preload), NSK 7911CTYNDULP4 (light preload, polyamide cage), Fafnir 2MM9311WI DUL (light preload). Designation forms: 71911 CD/P4ADGA, 71911CDP4ADGA, 71911 CD P4A DGA.

Frequently asked questions:

How many bearings are in the SKF 71911 CD/P4ADGA set?

Two bearings, one factory-matched pair, universally matchable for any arrangement.

What contact angle and preload does the 71911 CD/P4ADGA have?

Contact Angle: 15° (CD). Preload: extra light, 70 N (A).

What size and precision class is the 71911 CD/P4ADGA?

55 mm bore, 80 mm outside diameter, 13 mm width per bearing. Precision Class: ABEC 7 / P4A.
