FAG HCS71907E.T.P4S.UL hybrid ceramic sealed angular contact ball bearing, 35 x 55 x 10 mm, 25° contact angle, non-contact lip seals both sides, ABEC 7 / P4.
List Price
$166.60
4 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | HCS71907E.T.P4S.UL |
| GTIN | 4012801483612 |
| Model | HCS 71907 E T P4S UL / 7907 |
| Bearing Type | Angular Contact Ball Bearing, Lip seals both sides, non-contact |
| ID | 35 mm |
| OD | 55 mm |
| Width | 10 mm |
| Base Number | HCS71907 |
|---|---|
| Mpn Variants | HCS71907E.T.P4S.UL; HCS71907ETP4SUL; HCS-71907-E-T-P4S-UL; HCS 71907 E T P4S UL; 71907; 7907 |
| Precision Class | ABEC 7 / P4 |
| Additional Attributes | Fatigue load limit radial 275 N; preload per pair light 26 N, medium 78 N, heavy 155 N; operating temperature -30 to +80 C |
| Material | Silicon nitride ceramic balls, chrome steel rings |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 6,100 N |
| Static Load Rating | 3,450 N |
| Precision Rating | ABEC 7 / P4 |
| Series | HCS719 |
| Rolling Elements | Ball |
| Max Temp | 80 °C |
| Item Weight | 0.075 kg (0.17 lb) |
| Cage Material | Phenolic |
| Limiting Speed | 40,000 rpm grease |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Lubricant | Grease |
| Contact Angle | 25° |
| Preload | Universal; light 26 N, medium 78 N, heavy 155 N per pair |
| Mounting Arrangement | Universal — back-to-back, face-to-face or tandem |
| Bearing Material | Silicon nitride ceramic balls, chrome steel rings |
| Part Number | HCS71907E.T.P4S.UL |
| Industry Terms | hybrid ceramic angular contact ball bearing; sealed spindle bearing; high speed spindle bearing; 7907 spindle bearing; 25 degree ceramic ball bearing |
| Common Misspellings | FGA HCS71907E.T.P4S.UL; HSC71907E.T.P4S.UL; FAG HCS 71907 ETP4S UL; FAG HCS71907E T P4S |
| Application Types | Machine tool spindles; high-speed grease-lubricated spindles |
| Closure Type | Lip seals both sides, non-contact |
| Cross Reference 1 | SKF 71907 ACE/HCP4A - open, no seals |
|---|
FAG HCS71907E.T.P4S.UL is a hybrid ceramic, sealed, super-precision spindle angular contact ball bearing, universally ground for matching in pairs or sets. Unit Quantity: 1 Pc. GTIN: 4012801483612.
HCS — hybrid ceramic execution with a sealed outer ring; silicon nitride balls run in steel rings.
B719 section — the extra-light 719 cross-section.
71907 — ISO size code. Bore 35 mm, outside diameter 55 mm, width 10 mm.
E — contact angle 25°.
T — fabric-base laminate phenolic cage, machined.
P4S — Precision Class: ABEC 7 / P4.
UL — universally matchable in pairs or sets.
Bore Diameter: 35 mm. Outside Diameter: 55 mm. Overall Width: 10 mm. Contact Angle: 25°. Number Of Rows: 1. Rolling Elements: Ceramic ball. Dynamic Load Rating: 6,100 N. Static Load Rating: 3,450 N. Limiting Speed: 40,000 rpm grease. Fatigue load limit, radial: 275 N. Precision Class: ABEC 7 / P4. Cage Material: Phenolic. Cage Type: Machined. Closure Type: Lip seals both sides, non-contact. Lubricant: Grease. Operating temperature range: -30 °C to +80 °C. Series: HCS719. Base Number: HCS71907.
Bore Diameter: 35 mm. Outside Diameter: 55 mm. Overall Width: 10 mm. Bore Type: Straight. Item Weight: 0.075 kg (0.17 lb). Mounting Arrangement: Universal — back-to-back (O), face-to-face (X) or tandem. Preload per matched pair: light 26 N, medium 78 N, heavy 155 N.
Cross-Reference: SKF 71907 ACE/HCP4A (25° hybrid ceramic, open, no seals). MPN variants: HCS71907E.T.P4S.UL, HCS71907ETP4SUL, HCS-71907-E-T-P4S-UL, HCS 71907 E T P4S UL, 71907, 7907.
Bore 35 mm, outside diameter 55 mm and width 10 mm.
Dynamic load rating 6,100 N, static load rating 3,450 N and limiting speed 40,000 rpm on grease.
E is a 25° contact angle, T is a machined phenolic cage and P4S is Precision Class ABEC 7 / P4.
