Availability:
1 in stock
Super-precision spindle angular contact ball bearing, 55 x 90 x 18 mm, 15° contact angle, phenolic cage, universally matchable for any arrangement.
List Price
$134.73
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | B7011CBTPAP4UL |
| Model | B 7011 C B TPA P4 DUL / 2MM9111WI CR DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 55 mm |
| OD | 90 mm |
| Width | 18 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Preload | Light |
| Base Number | B7011 |
| Mpn Variants | B7011CB.TPA.P4.UL; B7011CBTPAP4UL; B-7011-CB-TPA-P4-DUL; B 7011 C B TPA P4 UL; B7011-C-T-P4S-UL; 2MM9111WI CR DUL; 7011C |
| Precision Class | ABEC 7 / P4 |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 38,500 N |
| Static Load Rating | 22,100 N |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 100 °C |
| Item Weight | 0.37 kg (0.82 lb) |
| Cage Material | Phenolic |
| Limiting Speed | 16,000 rpm grease; 24,000 rpm oil |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Internal Clearance | N/A |
| Lubricant | Grease or oil |
| Harmonization Code | 8482.10.50.68 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal — back-to-back, face-to-face or tandem |
| Bearing Material | Chrome steel |
| Part Number | B7011CB.TPA.P4.UL |
| Cross Reference 1 | SKF 7011 CD/P4A |
|---|---|
| Cross Reference 2 | NSK 7011C |
| Cross Reference 3 | NTN 7011C |
| Cross Reference 4 | Timken Fafnir 2MM9111WI |
| Cross Reference 5 | RHP 7011CT |
| Cross Reference 6 | Koyo 7011C |
FAG B7011CB.TPA.P4.UL is a super-precision spindle angular contact ball bearing. Bore Diameter: 55 mm. Outside Diameter: 90 mm. Overall Width: 18 mm. Contact Angle: 15°. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Bearing Material: Chrome steel. Item Weight: 0.37 kg (0.82 lb).
B70 — Schaeffler’s spindle bearing series in the light 70 section.
7011 — ISO size code. Bore 55 mm, outside diameter 90 mm, width 18 mm.
C — Contact angle 15°.
TPA — Fabric-base laminate phenolic cage, machined.
P4 — Precision Class: ABEC 7 / P4.
UL — Universally matchable. Faces are ground so any two or more bearings pair in back-to-back, face-to-face or tandem arrangement and reach the published preload without shims.
Dynamic Load Rating: 38,500 N. Static Load Rating: 22,100 N. Limiting Speed: 16,000 rpm grease; 24,000 rpm oil. Fatigue load limit, radial: 2,340 N.
Precision Class: ABEC 7 / P4. Cage Material: Phenolic. Cage Type: Machined. Lubricant: grease or oil. Operating temperature range: -30 °C to +100 °C.
A 15° contact angle carries more radial load and runs faster than a 25° execution of the same size. Series: B70. Base Number: B7011.
Preload per matched pair: light 205 N, medium 670 N, heavy 1,344 N.
Mounting Arrangement: Universal — back-to-back (O), face-to-face (X) or tandem. Internal Clearance: N/A; the bearing is preload-adjusted rather than clearance-set.
Unit Quantity: 1 Pc. Single bearing, universally ground, ready to be matched with further pieces of the same designation.
Same-envelope, same-angle, same-class equivalents: SKF 7011 CD/P4A, NSK 7011C, NTN 7011C, Timken Fafnir 2MM9111WI, RHP 7011CT and Koyo 7011C.
Searchable forms of the number: B7011CB.TPA.P4.UL, B7011CBTPAP4UL, B-7011-CB-TPA-P4-DUL, B 7011 C B TPA P4 UL, B7011-C-T-P4S-UL, 2MM9111WI CR DUL, 7011C.
