Availability:
1 in stock
Super-precision angular contact ball bearing pair, 35 x 62 x 14 mm, 15° contact angle, ABEC 7 / P4, medium preload. SKF 7007 CD/P4ADGB equivalent.
List Price
$128.49
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | EX35-7CE1DUM |
| Model | 2MM-9107 WI DUM / 7007 P4 DUM / EX 35-7 CE 1 DUM 16° |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 35 mm |
| OD | 62 mm |
| Width | 14 mm |
| Material | Bearing Steel |
|---|---|
| Series | EX |
| Preload | Medium |
| Mpn Variants | EX35-7CE1DUM, EX 35 7CE1 DUM, EX35-7-CE-1-DUM, EX 35-7 CE 1 DUM |
| Precision Class | ABEC 7 / P4 |
| Closure Type | Open |
| Cage Type | Outer-ring guided |
| Dynamic Load Rating | 15,600 N |
| Static Load Rating | 9,500 N |
| Rolling Elements | Ball |
| Item Weight | 0.15 kg (0.33 lb) |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 24,000 rpm grease; 36,000 rpm oil |
| Harmonization Code | 8482.10.50.68 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal matched pair (back-to-back, face-to-face or tandem) |
| Cross Reference 1 | SKF 7007 CD/P4ADGB |
|---|---|
| Cross Reference 2 | SKF 7007 CDGB/P4A |
| Cross Reference 3 | NSK 7007CTYNDUMP4 |
| Cross Reference 4 | FAG B7007-C-T-P4S-UM |
| Cross Reference 5 | Fafnir 2MM9107WICRDUM |
SNFA EX35-7CE1DUM is a matched set of two super-precision single-row angular contact ball bearings from the SNFA EX high-capacity series, ISO dimension series 10. Bore Diameter: 35 mm. Outside Diameter: 62 mm. Width: 14 mm per bearing. Contact Angle: 15°. Precision Class: ABEC 7 / P4. The current SKF equivalent is the 7007 CD/P4ADGB high-capacity D design pair.
EX — SNFA high-capacity angular contact series, ISO dimension series 10 (70xx envelope).
35 — bore diameter in millimetres.
7 — SNFA precision grade, ABEC 7 (ISO P4).
C — phenolic resin cage.
E — cage centred on the outer ring.
1 — 15° nominal contact angle.
DU — universal duplex set: two bearings ground for back-to-back, face-to-face or tandem mounting.
M — medium preload.
Dynamic Load Rating: 15,600 N per bearing. Static Load Rating: 9,500 N per bearing. Limiting Speed: 24,000 rpm grease; 36,000 rpm oil-air, single bearing. The 15° angle favours radial stiffness and speed; medium preload balances stiffness against running temperature.
Item Weight: 0.15 kg (0.33 lb) per bearing. Cage Type: Outer-ring guided. Cage Material: Phenolic. Closure Type: Open.
Unit Quantity: 2 Pcs. Mounting Arrangement: Universal matched pair, back-to-back, face-to-face or tandem. Preload: Medium.
SKF owns SNFA and lists the EX series as the SNFA equivalent of its 70 .. CD range. Cross-references with the same 35 x 62 x 14 mm envelope and 15° nominal contact angle: SKF 7007 CD/P4ADGB, SKF 7007 CDGB/P4A, FAG B7007-C-T-P4S-UM, NSK 7007CTYNDUMP4, Fafnir 2MM9107WICRDUM.
