Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

RHP

7009CTRDULP3

Angular Contact Ball Bearing – 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Light preload.

Condition: New

Model #: 7009 C TR DUL P3 / 2M9109WI CR DUL

Availability:

1 in stock

Categories: Bearing & Bushing Parts

Product Description

Can’t find a part you’re looking for? CLICK HERE TO CONTACT US!-We can get all parts needed at competitive prices -International shipping is offered on every item and all orders-Shipping is combined on all orders-Collect Shipping offered for UPS, Fedex, DHL, FreightSAME DAY SHIPPING ON ALL ITEMSNEXT DAY SHIPPING AVAILABLE AT CHECKOUT

Same day shipment

List Price

$187.32

1 in stock

Also Available From:

Need Help?
Click Here To Contact Support

Specifications

Additional information

Key Specifications

MFR / Brand	RHP
MPN	7009CTRDULP3
Model	7009 C TR DUL P3 / 2M9109WI CR DUL
Bearing Type	Angular Contact Ball Bearing, Open
ID	45 mm
OD	75 mm
Width	16 mm

Specifications

Advertise	1
Material	Bearing Steel
Cage Type	Outer Ring Guided
Dynamic Load Rating	25.6 kN / 5755 lbf
Static Load Rating	19.3 kN / 4339 lbf
Precision Rating	ABEC 9 / P3
Series	7000
Rolling Elements	Ball
Max Temp	120 °C
Condition	New
Item Weight	1.05 lbs
Cage Material	Phenolic Resin
Limiting Speed	19200 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Contact Angle	15°
Preload	Light
Mounting Arrangement	Universal

Seller Part Number: B-AC4B3#BDJUYG
