Photo may not represent actual item. Refer to name and product specs for all details.
Availability:
10 in stock
List Price
$167.63
10 in stock
10 in stock
Get Estimated Arrival Date
Angular Contact Ball Bearing – 20 mm ID, 42 mm OD, 12 mm Width, Open, 15°, Light preload.
| MFR / Brand | SKF |
|---|---|
| MPN | 7004CDP4ADGA |
| Model | 7004CD/P4A DGA 7004C |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 20 mm |
| OD | 42 mm |
| Width | 12 mm |
| Material | Bearing Steel |
|---|---|
| Unit Type | Unit |
| Unit Quantity | 1 |
| Min Temp | -30 °C |
| Dynamic Load Rating | 8.71 kN / 1958 lbf |
| Static Load Rating | 4.3 kN / 967 lbf |
| Precision Rating | ABEC 7 / P4 |
| Series | 7000 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Condition | New |
| Item Weight | 0.31 lbs |
| Cage Material | Phenolic |
| Limiting Speed | 56000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Internal Clearance | C0 |
| Lubricant | Oil |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Preload | Light Preload |
| Mounting Arrangement | Universal |
| Mounting Style | Dual Ground Flush |
| Radial Dynamic Load Capacity | 8.71 kN |
| Abec | ABEC7 (ISO Class 4) |
| Max Rpm | 56000 RPM |
| Radial Static Load Capacity | 4.3 kN |
| Cross Reference 1 | FAG B7004CB.TPA.P4.DUL |
|---|---|
| Cross Reference 2 | NSK 7004CTRDULP4Y |
| Cross Reference 3 | NTN 7004CVDUJ74 |
