Availability:
1 in stock
Single direction thrust ball bearing, 100 mm bore, 135 mm OD, 25 mm high, pressed steel cage. FAG 51120, axial load rating 85,000 N dynamic.
List Price
$63.44
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 51120 |
| GTIN | 4012801197601 |
| Model | 51120 |
| ID | 100 mm |
| OD | 135 mm |
| Width | 25 mm |
| Dynamic Load Rating | 85,000 N |
|---|---|
| Static Load Rating | 268,000 N |
| Precision Rating | PN |
| Series | 51100 |
| Max Temp | 150 °C |
| Min Temp | -30 °C |
| Rolling Elements | Ball |
| Bearing Type | Thrust Ball Bearing, Open |
| Item Weight | 0.992 kg (2.187 lb) |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Limiting Speed | 2,400 rpm |
| Cage Type | Pressed sheet steel cage (JP) |
| Overall Width | 25 mm |
| Mpn Variants | 51120, FAG51120, 51120-FAG |
| Compatible With Replaces | SKF 51120, NSK 51120, NTN 51120, Koyo 51120, Timken 51120 |
| Precision Class | PN |
| Additional Attributes | Load direction: axial, single direction; Reference Speed: 3,100 rpm; Housing washer bore: 102 mm |
| Industry Terms | single direction thrust ball bearing; axial ball bearing; flat race thrust bearing; 100x135x25 thrust bearing |
| Common Misspellings | FAG51120; FAG 51 120; FAG 5120; Fag thrust bearing 51120 |
| Application Types | Axial load support on shafts; vertical shaft thrust loads; screw and pump thrust positions |
| Cross Reference 1 | SKF 51120 |
|---|---|
| Cross Reference 2 | NSK 51120 |
| Cross Reference 3 | NTN 51120 |
| Cross Reference 4 | Koyo 51120 |
| Cross Reference 5 | Timken 51120 |
FAG 51120 single direction thrust ball bearing, 100 mm bore x 135 mm outside diameter x 25 mm height. It carries axial load in one direction and consists of a shaft washer, a housing washer and a ball and cage assembly. One bearing.
511 — single direction thrust ball bearing, dimension series 11.
20 — bore code; 20 x 5 = 100 mm bore.
Bore Diameter: 100 mm. Outside Diameter: 135 mm. Overall Width: 25 mm. Rolling Elements: Ball. Number Of Rows: 1. Dynamic Load Rating: 85,000 N (axial). Static Load Rating: 268,000 N (axial). Limiting Speed: 2,400 rpm. Reference Speed: 3,100 rpm. Cage Material: Pressed steel (JP). Precision Class: PN normal tolerance. Operating Temperature: -30 to 150 °C. Item Weight: 0.992 kg (2.187 lb). GTIN: 4012801197601. Unit Quantity: 1 Pc.
Shaft washer bore d: 100 mm. Housing washer bore: 102 mm.
Cross-references: SKF 51120, NSK 51120, NTN 51120, Koyo 51120, Timken 51120. Size: 100 x 135 x 25 mm.
Bore 100 mm, outside diameter 135 mm, height 25 mm.
Dynamic load rating 85,000 N and static load rating 268,000 N, axial.
Limiting speed 2,400 rpm and reference speed 3,100 rpm.
