Fafnir

2MMVC9114HXCRTUL

Angular Contact Bearing – 70 mm ID, 110 mm OD, 20 mm Width, Open, 15° Contact Angle

Condition: New

Model #: 2 MMV C 9114 HX CR TUL 7014 C HC P2 TUL FS735 HY-CERAMIC ABEC9

Availability:

1 in stock

Categories: Bearing & Bushing Parts

Product Description

The Fafnir 2MMVC9114HXCR-SUL Bearing is a high-quality Angular Contact Ball Bearing with a bore diameter of 70mm and an outside diameter of 110mm. Made of steel and having a width of 20mm, this bearing is designed for industrial automation and motion control applications. Manufactured in the United States by FAFNIR, a reputable brand in the bearings industry, this bearing is suitable for various mechanical power transmission systems requiring precision and durability.

Same day shipment

List Price

$992.17

1 in stock

Also Available From:

Need Help?
Click Here To Contact Support

Specifications

Additional information

Key Specifications

MFR / Brand	Fafnir
MPN	2MMVC9114HXCRTUL
Model	2 MMV C 9114 HX CR TUL 7014 C HC P2 TUL FS735 HY-CERAMIC ABEC9
Bearing Type	Angular Contact Ball Bearing, Open
ID	70 mm
OD	110 mm
Width	20 mm

Specifications

Advertise	1
Material	Steel
Min Temp	-30 °C
Cage Type	Machined
Dynamic Load Rating	39 kN / 8770 lbf
Static Load Rating	40 kN / 9000 lbf
Precision Rating	ABEC 9 / P2
Series	9100
Rolling Elements	Ceramic Balls
Max Temp	120 °C
Condition	New
Item Weight	1.41 lbs
Cage Material	Phenolic
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Contact Angle	15°
Preload	Light
Mounting Arrangement	Universal

Cross-References

Cross Reference 1	SKF 7014 CDGA/HCP4A
Cross Reference 2	NSK 7014CTYNSULP4
Cross Reference 3	GMN HYS6014CTA
