Angular Contact Ball Bearing – 35 mm ID, 55 mm OD, 10 mm Width, Open, 25° Contact Angle, Light Preload.

Angular Contact Ball Bearing – 35 mm ID, 55 mm OD, 10 mm Width, Open, 25° Contact Angle, Light Preload.

Angular Contact Ball Bearing – 35 mm ID, 55 mm OD, 10 mm Width, Open, 25° Contact Angle, Light Preload.

Angular Contact Ball Bearing – 35 mm ID, 55 mm OD, 10 mm Width, Open, 25° Contact Angle, Light Preload.

Angular Contact Ball Bearing – 35 mm ID, 55 mm OD, 10 mm Width, Open, 25° Contact Angle, Light Preload.

Angular Contact Ball Bearing – 35 mm ID, 55 mm OD, 10 mm Width, Open, 25° Contact Angle, Light Preload.

SNR

71907 H Q16 J75

Angular Contact Ball Bearing – 35 mm ID, 55 mm OD, 10 mm Width, Open, 25° Contact Angle, Light Preload.

Condition: New

Model #: 7907A5/ACD 7907E T DUL P4 / 3MM9307WI CR DUL / 71907 H G1 DU J74

Availability:

1 in stock

Categories: Bearing & Bushing Parts

Product Description

The SNR 71907HQ16J75 Angular Bearing is a high-quality angular contact ball bearing designed for industrial automation and motion control applications. Made of durable steel material and manufactured in France, this bearing has a bore diameter of 35mm, outside diameter of 55mm, and a width of 10mm. With its precise dimensions and reliable performance, this bearing is a crucial component for ensuring smooth and efficient mechanical power transmission in various machinery and equipment.

List Price

$66.70

1 in stock

Also Available From:

Need Help?
Click Here To Contact Support

Specifications

Additional information

Key Specifications

MFR / Brand	SNR
MPN	71907 H Q16 J75
Model	7907A5/ACD 7907E T DUL P4 / 3MM9307WI CR DUL / 71907 H G1 DU J74
Bearing Type	Angular Contact Ball Bearing, Open
ID	35 mm
OD	55 mm
Width	10 mm

Specifications

Advertise	1
Material	Steel
Unit Type	Unit
Unit Quantity	1
Min Temp	-30°C
Cage Type	Phenolic
Dynamic Load Rating	13.5 kN
Static Load Rating	9.3 kN
Precision Rating	ABEC 7 / P4
Rolling Elements	Balls
Max Temp	120°C
Condition	New
Item Weight	0.16 lbs
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Contact Angle	25°
Preload	Light
Mounting Arrangement	Universal
Running Accuracy	P4
Part Number	71907HQ16J75
Running Accuracy Radial And Axial Runout	P4

Cross-References

Cross Reference 1	SKF 71907 CD/P4A
Cross Reference 2	FAG HCB71907-C-T-P4S

Seller Part Number: AA1B3#NCS6EZ
