NTN

7000CDBGNP5

Angular Contact Ball Bearing – Straight Bore, 10mm ID, 26mm OD, 8mm Width, Open, 15° Contact Angle, Phenolic Cage, P5 Precision.

Condition: New
Model #: 7000 C DB GN P5

Availability:

1 in stock

Product Description

NTN 7000CDBGNP5-1/2PR Angular Bearing – Precision Engineering for Optimal Performance

Discover the exceptional performance of the NTN 7000CDBGNP5-1/2PR Angular Bearing, perfectly engineered to meet the rigorous demands of your mechanical applications. With dimensions of 10x26x8 mm, this Angular Contact Ball Bearing is crafted to deliver unmatched durability and reliability.

Manufactured in Japan, a region renowned for its high-quality standards, the model 7000 C DB GN P5 features an angular contact design that significantly enhances load-carrying capacity. This makes it an ideal choice for applications requiring effective support of both axial and radial loads.

Key Features:

Brand: NTN
Type: Angular Contact Ball Bearing
Model Number: 7000 C DB GN P5
MPN: 7000CDBGNP5
Width: 8 mm

We are committed to delivering exceptional customer service. If you require a specific part, do not hesitate to contact us. Our dedicated team is ready to help you source parts at competitive prices.

Enjoy same-day shipping on all orders, with next-day options available at checkout. We provide international shipping, competitive combined shipping rates, and flexible collection services with leading carriers like UPS, FedEx, DHL, and Freight.

Upgrade your machinery’s performance today with the NTN 7000CDBGNP5 Angular Bearing. Order now and experience superior quality and service!

Same day shipment

List Price

$48.79

1 in stock

Availability

1 in stock

On the Shelf & Ready to Ship

Free Shipping

On all orders

Free Returns

No Risk, No Hassle

Also Available From:

Specifications

Additional information

Key Specifications

MFR / BrandNTN
MPN7000CDBGNP5
Model7000 C DB GN P5
Bearing TypeAngular Contact Ball Bearing, Open
ID10mm
OD26mm
Width8mm

Specifications

Advertise1
Min Temp-30°C
Cage TypePhenolic
Dynamic Load Rating5.4 kN / 1215 lbf
Static Load Rating2.5 kN / 560 lbf
Precision RatingABEC 5 / P5
Series7000
Rolling ElementsBalls
Max Temp120°C
ConditionNew
Item Weight0.088 lbs
Cage MaterialPhenolic
Limiting Speed41000 rpm
Number Of Rows1
Bore TypeStraight
Snap Ring IncludedWithout Snap Ring
LubricantOil
Harmonization Code8482.10.50
Contact Angle15°
PreloadNormal
Mounting ArrangementUniversal Pair
MaterialBearing Steel

Cross-References

Cross Reference 1SKF 7000 CD/P5
Cross Reference 2FAG B7000-C-P5
Cross Reference 3NSK 7000CTYNSULP5
Cross Reference 4GMN S6000 C TA P5
Cross Reference 5Koyo 7000C-5
