Name: Angular Contact Ball Bearing - 60 mm ID, 95 mm OD, 18 mm Width, Open, 15°, Light Preload
Brand: GMN
SKU: AO5B2#ITPLQF
Price: 197.3 USD
Availability: InStock

Additional information

Key Specifications

MFR / Brand	GMN
MPN	S6012CTAA7DUL
Model	S 6012 C TA A7 DUL / 2MM9112WI CR DUL / 7012C T P4 DUL / ABEC7
Bearing Type	Angular Contact Ball Bearing, Open
ID	60 mm
OD	95 mm
Width	18 mm

Specifications

Advertise	1
Material	Bearing Steel
Series	6000
Condition	New – Open box
Lubricant	None
Preload	Light Preload
Cage Type	Machined
Dynamic Load Rating	33.5 kN / 7531 lbf
Static Load Rating	31.5 kN / 7081 lbf
Precision Rating	ABEC 7 / P4
Rolling Elements	Ball
Max Temp	100°C
Item Weight	0.90 lbs
Cage Material	Phenolic
Limiting Speed	17000 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Contact Angle	15°
Mounting Arrangement	Universal
Running Accuracy	High Precision
Running Accuracy Radial And Axial Runout	High Precision

Cross-References

Cross Reference 1	SKF 7012 CD/P4ADGA
Cross Reference 2	RHP 7012CTRDULP4
