Photo may not represent actual item. Refer to name and product specs for all details.
Availability:
1 in stock
List Price
$90.85
1 in stock
1 in stock
Get Estimated Arrival Date
| Weight | 5 lbs |
|---|---|
| Dimensions | 6 × 6 × 2 in |
| Brand | Fafnir |
| MPN | 2MM216WIDUH |
| Width | 26 mm |
| model | ABEC7 / 2 MM 216 WI CR DUH / 7216 C D P4A / 216HDH |
| bearings type | Angular Contact Ball Bearing |
| bore diameter | 80 mm |
| outside diameter | 140 mm |
| min temp | -30°C |
| cage type | Phenolic |
| seal type | Open |
| dynamic load rating | 90 kN |
| static load rating | 83 kN |
| precision rating | ABEC 7 / P4 |
| rolling elements | Balls |
| max temp | 120°C |
| package type | PackageThickEnvelope |
| Condition | New – Open box |
| Bearing type | Angular Contact Ball Bearing |
| Item weight | 3.20 lbs |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap ring included | Without Snap Ring |
| Cross-Reference 1 | SKF 7216 CD/P4ADGC |
| Cross-Reference 2 | RHP 7216ETDUHP4 |
| Woo-Title | Angular Contact Ball Bearing – 80 mm ID, 140 mm OD, 26 mm Width, Open, 15° Contact Angle, Heavy Preload. |
| Contact Angle | 15° |
| Preload | Heavy |
| Mounting Arrangement | Universal |
| contant angle | 15° |
| running accuracy | P4 |
| Running Accuracy - Radial And Axial Runout | P4 |
| Limiting Speed | 9500 rpm |
| Material | Bearing Steel |
