Name: Angular Contact Ball Bearing - 45 mm ID, 75 mm OD, 15 mm Width, Open, 60°.
Brand: NSK
SKU: B-AC2B1#GQG5E4
Price: 144.27 USD
Availability: InStock

Additional information

Key Specifications

MFR / Brand	NSK
MPN	45TAC75BSUC8PN7B
Model	45 TAC 75 B SUC 8 PN 7B
Bearing Type	Angular Contact Ball Bearing, Open
ID	45 mm
OD	75 mm
Width	15 mm

Specifications

Advertise	1
Material	High Carbon Chrome Steel
Series	TAC
Condition	New
Cage Type	Rolling Element Guided
Dynamic Load Rating	28 kN / 6295 lbf
Static Load Rating	63 kN / 14163 lbf
Precision Rating	ABEC 7 / P4
Rolling Elements	Ball
Max Temp	120°C
Item Weight	0.52 lbs
Cage Material	Polyamide
Limiting Speed	5300 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Contact Angle	60°

Cross-References

Cross Reference 1	SKF BTM 45 A/P4CDBA
Cross Reference 2	FAG 7602045-TVP
Cross Reference 3	NTN 45TAB07
