Name: Angular Contact Ball Bearing - 50 mm ID, 72 mm OD, 12 mm Width, Open, 15°, Light preload.
Brand: RHP
SKU: B-AA4B2#NBIXNT
Price: 131.03 USD
Availability: InStock

Additional information

Key Specifications

MFR / Brand	RHP
MPN	7910CTSULP4
Model	7910 C T SUL P4 /71910 / 2MM9310WI CR DUL
Bearing Type	Angular Contact Ball Bearing, Open
ID	50 mm
OD	72 mm
Width	12 mm

Specifications

Advertise	1
Material	Bearing Steel
Series	7900
Condition	New
Preload	Light Preload
Cage Type	Outer Ring Guided
Dynamic Load Rating	15.3 kN / 3440 lbf
Static Load Rating	13.5 kN / 3035 lbf
Precision Rating	ABEC 7 / P4
Rolling Elements	Ball
Max Temp	120°C
Item Weight	0.28 lbs
Cage Material	Phenolic Resin
Limiting Speed	20000 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Contact Angle	15°
Mounting Arrangement	Universal

Cross-References

Cross Reference 1	SKF 71910 CDGA/P4A
Cross Reference 2	FAG B71910-C-T-P4S-UL
Cross Reference 3	NSK 7910CTRSULP4
