The NSK 7003CTRDUMP4Y Angular Bearing is a high-quality, steel-made bearing designed for industrial automation and motion control applications. With a bore diameter of 17mm, an outside diameter of 35mm, and a width of 10mm, these bearings provide smooth and precise motion support. Manufactured in the United Kingdom, this angular contact ball bearing model (7003 C TR DUM P4Y / 2MM9103 WI CR DUM) ensures reliable performance and durability in various mechanical power transmission systems. Ideal for use in bearings and bushings, this NSK product is a valuable component for machinery and equipment.
| MFR / Brand | NSK |
|---|---|
| MPN | 7003CTRDUMP4Y |
| Model | 7003 C TR DUM P4Y / 2MM9103 WI CR DUM |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 17 mm |
| OD | 35 mm |
| Width | 10 mm |
| Material | High Carbon Chrome Steel |
|---|---|
| Min Temp | -20 °C |
| Cage Type | Window |
| Dynamic Load Rating | 8.35 kN / 1877 lbf |
| Static Load Rating | 4.65 kN / 1045 lbf |
| Precision Rating | ABEC 7 / P4 |
| Series | 7000 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Condition | New |
| Item Weight | 0.09 lbs |
| Cage Material | Phenolic Resin |
| Limiting Speed | 60000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Lubricant | Oil |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Preload | Medium Preload |
| Mounting Arrangement | Universal |
| Cross Reference 1 | FAG B7003-C-T-P4S-DUM |
|---|---|
| Cross Reference 2 | SKF 7003 CD/P4A DGB |
