Availability:
7 in stock
List Price
$349.38
7 in stock
7 in stock
Get Estimated Arrival Date
| MFR / Brand | FAG |
|---|---|
| MPN | B7020C.TPA.P4S.UL |
| Model | 7020 TG P4 / 7020C / 2MM9120 UL / 120HDL / B7020CTP4UL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 100 mm |
| OD | 150 mm |
| Width | 24 mm |
| Material | Bearing Steel |
|---|---|
| Min Temp | -30°C |
| Cage Type | Outer Ring Guided |
| Dynamic Load Rating | 75 kN / 16861 lbf |
| Static Load Rating | 78 kN / 17535 lbf |
| Precision Rating | ABEC 7 / P4 |
| Series | 7000 |
| Rolling Elements | Ball |
| Max Temp | 100°C |
| Condition | New |
| Item Weight | 2.7 lbs |
| Cage Material | Phenolic Resin |
| Limiting Speed | 7500 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Lubricant | Grease |
| Relubrication Feature | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Preload | Light Preload |
| Mounting Arrangement | Universal |
| Running Accuracy | High Precision |
| Running Accuracy Radial And Axial Runout | High Precision |
| Cross Reference 1 | SKF 7020 CDGA/P4A |
|---|
The product is a high precision Angular Contact Ball Bearing manufactured by FAG in Germany. With a precision rating of ABEC 7 / P4 and a dynamic load rating of 75 kN, this bearing is designed for high reliability in industrial automation and motion control applications. It features a 15° constant angle, a bore diameter of 100 mm, and a static load rating of 78 kN. The bearing is made of bearing steel, lubricated with grease, and has a maximum temperature of 100°C. Its universal mounting arrangement and high running accuracy make it a versatile and efficient choice for various mechanical power transmission needs.
